3.2 RC Amphibious Car Battery Installation
1. Unscrew the upper cover screws and remove the upper cover.
2. Remove the battery compartment xing clip and remove the battery cover.
3. Connect the body and battery power cable, pay attention to the connect
direction of the interface.
4. Reinstall the battery cover and x the clip.
5. Install the upper cover and tighten the screws.
Attention
• When you install or remove the Car's battery cover, you can
remove it with a tool, be Careful not to scratch it.
• Make sure the battery cover clips are properly secured to prevent
the battery from falling into water.
• Please connect the battery and the body power interface correctly
to ensure that they are installed in place.
1601AMP User Manual
11
Copyright ©2022 Ruko All Rights Reserved.
