The Ruko 1601AMP is an amphibious remote-controlled vehicle designed for users aged 8 and above. This user manual provides comprehensive guidance for its operation, maintenance, and safety. It is recommended to watch all tutorial videos and read the user manual thoroughly before initial use to familiarize yourself with the product's functions and safety guidelines. If any questions arise before or during operation, Ruko's after-sales support team is available for assistance.

Function Description

The Ruko 1601AMP is a versatile RC car capable of operating on both land and water surfaces. It features a 2.4 GHz frequency band transmitter, allowing multiple users to play simultaneously without significant interference. The vehicle is equipped with headlights and rear lights, which also serve as indicators for battery status. Its robust design allows for movement in various directions: forward, backward, turn left, turn right, and even rotational spins. The amphibious capability is a key feature, enabling transitions between land and water environments.

Usage Features

Preparation Before Play:

Before operating the 1601AMP, ensure all warnings are read and understood. Proper battery installation is crucial for safe operation. When installing or removing the battery cover, use appropriate tools carefully to avoid scratches. Always ensure the battery cover screws are properly tightened to prevent water ingress and battery dislodgement, especially when operating in water. Both the transmitter and the RC car should use fully charged batteries to prevent loss of control. For optimal battery life, charge the battery with a 5V=2A USB charger for sufficient time. Note that the RC car's battery is initially charged to about 60% and will achieve longer life after 2-3 charge-discharge cycles. When playing on water, children must be supervised by adults to prevent drowning.

Transmitter Operation:

The transmitter operates on a 2.4 GHz frequency. On land, the unobstructed transmission distance is up to 40 meters, while on water, it is about 20 meters.

Pairing Frequency: To pair the RC car with the transmitter, first turn on the RC car's power switch, then turn on the remote control switch. The frequency pairing will occur automatically, indicated by the lights on both the car and transmitter changing from flashing to a steady light.
Land Mode Controls:
- Forward: Long press the upper arrow on the left button.
- Backward: Long press the lower arrow on the left button.
- Turn Left: Press the left arrow on the right button.
- Turn Right: Press the right arrow on the right button.
- Rotate Left: Press and hold the left arrow on the right button.
- Rotate Right: Press and hold the right arrow on the right button.
- Combined Movements: The manual also details combined movements like "Forward + turn left" or "Back + turn right" by simultaneously pressing the respective arrows on both the left and right buttons.
Steering Sensitivity: The steering range and sensitivity depend on how hard and long the steering stick is turned. Practice is recommended to master steering amplitude and avoid loss of control.
Low Battery Indication: If the RC car's lights flash rapidly during operation, it indicates a low battery, and the battery should be replaced or recharged.

Surface Mode Operation:

The transmitter stick control method remains the same as in land mode. However, the vehicle's performance changes when on water. The amphibious vehicle will be slower (approximately 1.5 km/h compared to 10 km/h on land) and less sensitive to steering due to surface resistance. Consequently, battery life and transmitter distance will be shortened (approximately 22 minutes on water compared to 20 minutes on land).

Battery Installation (RC Car):

Unscrew and remove the upper cover.
Remove the battery compartment fixing clip and the battery cover.
Connect the body and battery power cable, ensuring correct polarity.
Reinstall the battery cover and fix the clip.
Install the upper cover and tighten the screws. When installing or removing the car's battery cover, use a tool carefully to avoid scratches. Ensure the battery cover clips are properly secured to prevent the battery from falling into water. Connect the battery and body power interface correctly for proper installation.

Maintenance Features

Daily Maintenance:

After use, power off the vehicle, then turn off the transmitter, and remove the battery.
Regularly clean the car to remove foreign objects like mud and sand.
It is normal for the motor and the bottom of the car to heat up during use.
Allow the battery to cool down before charging after use.
After driving in the sea, on the beach, or in mud, remove the batteries, wash and dry the car, and store it in a cool, dry place to prevent corrosion or rust.
The day after washing, check if the car moves normally to ensure it was properly rinsed and not stuck.

Battery Charging and Maintenance:

The RC car battery has a capacity of 850mAh and a rated voltage of 7.4V.
Use the original 5V/2A USB charging plug (self-provided) and the included charging cable.
During charging, the green indicator light on the charger will flash; it will turn steady green when charging is complete.
The normal charging time is about 3 hours. Remove the charger promptly after charging is completed.
Do not charge the battery immediately after use; allow it to cool down first to prevent damage.
After charging, disconnect the charging device from the battery. Regularly inspect the charging device and battery for any damage. Do not use alcohol or other flammable substances to clean the charging device.
It is recommended to charge and discharge the battery once a month. Do not store it with a full charge; maintain 50%-60% power. The ideal storage temperature is 19-21°C (within a range of 10-40°C).
If the battery accidentally falls into water, remove it immediately and place it in a safe, open area or an explosion-proof box until completely dry. Do not use it again, as water contact can cause decomposition and potential ignition or explosion.
If the battery catches fire, use solid fire extinguishing equipment like sand or a dry powder extinguisher.
Never use leaked or damaged batteries, or charge them if they emit odor, heat, deform, discolor, or show any other abnormal phenomena.
Avoid mechanical impact, crushing, or throwing the battery. Do not place heavy objects on the battery or charging device. If the battery has been dropped or subjected to external force, do not use it again.
The electrolyte inside the battery is highly corrosive. If it contacts skin or eyes, rinse with clean water for at least 15 minutes and seek medical attention.
Do not heat the battery or expose it to fire.
Do not carry the battery in pockets, backpacks, or drawers to prevent short circuits with other items. Avoid short-circuiting the positive and negative electrodes with wires or metal objects.
If the battery interface is dirty, wipe it with a clean, dry cloth to ensure good contact and prevent energy loss or charging failure.
Remove the battery power cord and cable when not in use. Pay attention to polarity when installing or replacing the battery.
Do not use fast chargers that exceed the battery's rated power; use a 5V/2A USB charger.
If the RC car is not used for a long time, remove the battery to prevent prolonged low power discharge.

Environmental Guidelines:

Waste batteries must not be disposed of with household waste.
Batteries are hazardous chemicals; contact local environmental or waste management agencies, the product supplier, or a battery recycling center for proper disposal according to local laws and regulations.

Original Accessories:

Only use original accessories to avoid injury and loss. Non-original accessories may compromise the safe use and performance of the RC car. Do not disassemble factory-installed components, as this may affect performance and cause accidents. The use of non-original charging cables and batteries is prohibited.

Common Issues & Solutions:

The manual provides a troubleshooting guide for common issues such as the car not responding, battery compartment clips not fixing firmly, the car not moving after battery connection, short battery life, battery not charging, charging cable not working, prolonged charging time, and lost control during turns. Solutions range from checking battery power and connections to ensuring proper charging practices and adjusting steering control. For instance, if the car doesn't respond, the battery might be low. If the battery won't charge, the charging cable or battery might be damaged, or the wrong USB charging head is being used. If the transmitter is out of frequency or damaged, a new remote control may be needed. For water leakage into the battery compartment, ensure the cover tabs are locked.

RUKO 1601AMP - Page 24
