PLEASE READ THIS CAREFULLY BEFORE YOU GETSTARTED
BE CAREFUL
Your winch rope is secured into the drum with an alumin-
ium crimp. This crimp is held in place with a grub screw.
If you are walking the rope out make sure not to pull it all
the way out with too much force as this could cause the
rope to separate from the crimp. (They are well secured
but with enough force it will come out) If you are taking
the rope o for any reason, don’t forget to undo the grub
screw first before trying to pull the crimp out of the drum.
(This applies to synthetic rope and also steelcable).
When using the winch, a minimum of 5 tightly wrapped
turns of cable/rope must remain on the drum before
winching anyload.
FAQs
Where is my wireless remote controller?
This is packaged up with the control box.
Can I rotate my gearbox?
Yes you can. Please see instructions included
with the winch.
Can I rotate my motor?
Yes you can. Remove bolts that hold the motor
onto the main bracket. Rotate andre-fit.
Can I rotate my winch 180 degrees as this
will suit my fitmentbetter?
Yes you can. You MUST unspool all of the
rope and feed it onto the drum in the opposite
direction as before. The rope will now feed over
the top of the drum rather than from the bottom.
(Thestandard fitment position is having the
motor on the left and gearbox on the right when
looking at the winch front on). Follow the arrow
direction on your winch. Failure to change the
rope direction will likely damage your winch and
void yourwarranty.
How do I install the winch on my winchbar?
Please refer back to your winch bar manufacturer
for instructions on fitting this winch into your bar
if you are unsure. Ifyou do not have the manual,
the winch bar manufacturer should be able to
assistyou.
For all other information please visit
www.runvawinch.com.au/support
YOUR CONTROL BOX
Your winch is supplied with a 2in1 control box mounting
bracket system (for mounting the control box on top
of the winch) as well as a winch bar angled mounting
bracket.
2in1 Bracket for mounting the control box to the
winch itself
Bullbar Bracket for mounting control box to a
winchbar
