Runxin 51240B (F112BS) User Manual

MODEL 51240B/53540B/53640B/61240B/63540B/63640B
31
3.3. System Configuration and Flow Rate Curve
A. Product Configuration
①61240B/63540B/63640B Fixed bed control valve configuration with tank,
resin volume, brine tank and injector.
Tank Size
（mm）
Resin
Volume
（L）
Flow Rate
（t/h）
Brine Tank
Size (mm)
The Minimum Salt
Consumption for
Regeneration（Kg）
Injector
Model
φ1200×2400
2500
44.0
φ1240×1600
375.00
7803
φ1500×2400
3200
63.0
φ1360×1690
480.00
7804
Note: The flow rate calculation is based on linear velocity 25m/h; the
minimum salt consumption for regeneration calculation is based on salt
consumption 150g / L (Resin).
②51240B/53540B/53640B Filter control valve configuration with tank, filter
material.
Tank Size
Volume
of Filter
Material
Carbon Filter
Sand Filter
Filtering
Flow Rate
Backwash
Flow Rate
Filtering
Flow Rate
Backwash
Flow Rate
mm
L
m
3
/h
m
3
/h
m
3
/h
m
3
/h
φ900×2400
900
7.6
22.9
15.9
34.3
φ1000×2400
1100
9.5
28.2
19.6
42.4
φ1200×2400
1500
13.5
40.7
28.2
61.0
Note: the filtering flow rate of carbon filter is calculated based on the 12m/h
operation rate; the backwash flow rate is calculated based on the
10L/(m
2
*s) backwash intensity; the filtering flow rate of sand filter is
calculated based on the 25m/h operation rate; the backwash flow rate is

Runxin 51240B (F112BS) Specifications

General

Brand	Runxin
Model	51240B (F112BS)
Category	Control Unit
Language	English
