Runxin F117Q1 User Manual

MODEL：F67Q/F71Q/F68Q/F69Q/F116Q/F117Q
49
③ Press or continuously until in service status, the digital
display area shows:4-12M；
④ Press , 12 flashes；
⑤ Press continuously until 12 change to 15；
⑥ Press again and hear a sound “Di” ， the frame stop
flickering，the program returns to enquiry status.；
⑦ If you want to adjust other parameters, you can adjust as above
3-5 steps; if not, press to exit the program inquiry status. The display
are shows the current working status.

Runxin F117Q1 Specifications

General

Model	F117Q1
Category	Control Unit
Max. Water Production Capacity	4 m³/h
Drain	1/2" NPT
Brine Line Connector	3/8 inch
Base	2 1/2"-8NPSM
Riser Pipe	1.05"
Water Pressure	0.15 - 0.6 MPa
