Runxin F69Q1 User Manual

MODEL：F67Q/F71Q/F68Q/F69Q/F116Q/F117Q
57
5447020 Flow Meter 5457003 Animated Connector
5447020 Flow Meter 5457003 Animated Connector
Item
No.
Description Part No.
Quan
tity
Item
No.
Description Part No.
Qua
ntity
1 Connector 8458014 1 1 Connector 8458014 1
2 O-ring 8378064 1 2 O-ring 8378064 1
3
Impeller
supporter
5115023 1 3 Clip 8270005 1
4 Impeller 5436013 1 4 Connector 8458039 1
5
Impeller
supporter
5115024 1
6 Clip 8270005 1
7 Shell 8002006 1

Runxin F69Q1 Specifications

General

Water Pressure	0.15 - 0.6 MPa
Transformer Input	100-240V AC, 50/60Hz
Max Flow Rate	4 m3/h
Drain	1/2" NPT
Brine Line Connector	3/8''
Riser Pipe	1.05'' OD
