9
VACUUM FEATURE DIAGRAM
1 Dust Bin Release Button 12 Hose Connection
2 Dust Bin Handle 13 Chassis
3 Dust Bin Lid 14 Base Chassis
4 Dust Bin 15 On/Off Switch
5 Flexible Hose 16 Cord Rewind Switch
6 Hose Handle 17 HEPA Filter Exhaust
7 Airflow Regulator 18 Filter Cover
8 Telescopic Tube 19 Sponge Filter
9 Floorhead 20 Multi Cyclonic Filter
10 2 in 1 Crevice Brush 21 Dust Bin Opening Button
11 Hose Release Button 22 Dust Bin Opening
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
