Ruud UIWH18AVFJ - Dimensions; Models:uiwh18 Avfj, and UIWH24 AVFJ

2. Dimensions
2-1. Models:UIWH18AVFJ, and UIWH24AVFJ
39-5/16 (998)
9 (238)
12-5/8 (320)
39-5/16 (998)
Outline of unit
18-9/16 (471)
2-5/8 (67)
1-1/8 (28)
1-13/16 (46)
17-1/4 (438)2-3/8 (61) 4 (102)15-5/8 (397)
17 (432)
2-3/16 (56)
2-3/16 (56)
3/8 (10)
12-5/8 (320)
11/16 (17)
Ø 3-1/8 (80) hole
Piping inlet
Ø 3-1/8 (80) hole
Piping inlet
Unit: in (mm)
- 3 -
WALL MOUNTED UIWH18-24AVFJ
