MATAWAY
SPECIFICATIONS
SPECIFICATIONS
Front axle........................... ... 3/4" (19 mm) diameter
mounted in self-aligning ball bearings
Rear axle................................ 3/4" (19 mm) diameter
welded to pivot arms
Blades.......Reversible, high carbon steel (hardened)
(blade thickness varies by reel)
1/32" (.8mm); 1/16" (1.5mm); 1/8" (3mm)
Chassis...............................3/16" (5 mm) formed and
welded steel plate
Clutch................................Belt tightener type for reel
and forward travel
Controls...............................Throttle control, lift lever
combined drive and reel clutch lever
Depth Adjustment.........................Micrometer screw
Depth of Cut....................................Up to 1" (25 mm)
Width of cut...19" (483 mm) with blade spacing from
1/2" (13 mm) to 2" (50.8 mm) depending
on which reel is used
Drive............"A" section belt from engine to gear box
No. 40 sealed roller chain from gearbox to front axle
Matched set of 3, V section belts from engine to reel
Engine.........Model No. GX390UT2, 11.7 H.P. Honda
Governor set at 3200 r.p.m. (no load).
Engine displacement: 23.7 cu. in. (389 cc) and
developes 18.5 ft.-lbs. (25.1 N·m)
of torque at 2500 r.p.m.
Gear Case........................................22 to 1 reduction
Reduction....................................Engine to reel - 1:1
Engine to wheels - 37.3:1
Reel.......................................Quick change mounting
Rotation in opposite direction of forward motion
Reel Speed...............................................3200 r.p.m.
Speed...214 ft./min.(65m/min.) at 3200 engine r.p.m.
Wheels...............Front; 4.10/3.50 - 4, pneumatic tires
chain driven
Rear; 4.10/3.50 - 4 pneumatic tires
free wheeling on self-aligning ball bearings.
Wheels on center line of reel to prevent
scalping on rolling terrain and scufng on turns.
Dimensions:
Width..........................................................36" (91cm)
Height...........................44" (112cm) including handle
Length..........................53" (135cm) including handle
Wheelbase...........................................16 1/2" (42cm)
Net Weight.........386 lbs. (175 Kg) with 544553Reel
Touch-up Paint:....... .5l spray can order PN 65334
.95l can order PN 65339
