33
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
MATAWAY
FIGURE 3
CLUTCH ASSEMBLY AND CONTROL
1 64006-03 WASHER, 3/8 HELICAL LCK 2
2 64163-55 WASHER .328X.75X14 GA 2
3 64001-10 NUT-HEX JAM 7/16-20 1
4 64123-89 BOLT-HEX 1/4-20X3/4 5
5 64123-82 BOLT-HEX 3/8-16X2-1/2 2
6 64168-2 COTTER-HAIRPIN.08X1.19 1
7 64025-04 NUT-3/8-24 HEX 1
8 64123-107 BLT-HEX 5/16-18X7/8 1
9 64025-01 NUT-1/4-20 HEX 1
10 4163596.7 BRACKET-CAM CONTROL 1
11 64123-50 BOLT-HEX 3/8-16X1 2
12 64123-69 BOLT-5/16-18X1-1/2 HEX 2
13 64025-15 NUT-HEX #10-24 KEPS 2
14 64025-05 NUT-3/8-16 HEX 2
15 64123-100 BOLT-3/8-16X2-1/4 HEX 1
16 64025-02 NUT-HEX 5/16-18 2
17 64140-1 COTTER PIN-1/8X1 2
18 64163-03 WSHR-.256X.62X18GA. 4
19 64163-67 WASHER-.516X1X12GA 1
20 516544 BUSHING (PLATING) 1
21 517226 BRG,SLV .33 .50 .20 IRON 1
22 2701258 SPRING, TSN 1.0X3.62X14 1
23 518487 SPRING 1
24 522882 PULLEY,IDLER 1
25 4163620.7 BRACKET, HANDLE 1
26 4163627.7 GUIDE, BELT 2
27 524507 NUT,SSPCL.312-18 Z HX 2
28 4166562 LINK (PLATING) 1
29 64229-03 NUT-NYLOCK 3/8-16 2
30 524561.7 ROD, CONTROL 1
31 4163633 CAM,CONTROL (PLATED) 1
32 4163634 TRIGGER,LOCKING PLTD 1
33 524577 BUSHING,.328X.63X.41 2
34 524579 CABLE,CONTROL 1
35 524585.7 HANDLE, CONTROL 1
36 4163745 COVER,VINYL 1
37 4163612.7 ARM AY 1
38 4163611.7 PIVOT 1
39 4163610.7 IDLER ARM 1
40 4163609.7 BRACKET 1
41 4163730 LEVER AY,CONTROL PLTD 1
42 822474 SPACER 1
43 64163-61 WSHR .81X.406X16GA 2
44 548171 KNOB 1
45 29-045 FITTING,GREASE 1/4 2
46 64188-36 PIN,CLEVIS 7/16X1-1/4 1
47 548507 CLEVIS 1
48 64141-6 NUT, 5/16-18 2
49 548942 PULLEY, PLAIN FLAT 3.25 1
50 64163-31 WSHR 25/64X1X12 2
51 64268-03 NUT-FL NYLON LOCK 3/8-16 1
52 64218-06 SCR-BTN HD 5/16-18X3/4 1
53 64151-18 NUT, HEX 1
54 64189-3A BLT-HEX SOC 1/4-20X5/8 2
55 64268-02 NUT-FL NYLN LCK 5/16-18 1
56 64262-006 BLT-FLG HD 5/16-18 X 3/4 1
57 64123-270 BLT-HEX 3/8-24X2-1/4 1
58 805421 SPRING,EXTENSION 1
59 64188-63 PIN-CLEVIS, 5/16 X 1.75 1
60 64163-86 WSHR-FLAT.265X.625X.125 2
61 64163-46 WSHR-.383/.393x.88 7GA 2
62 64163-04 WSHR-25-64X5/8X16GA 2
63 64229-01 NUT-NYLOCK 1/4-20 5
