35
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
MATAWAY
FIGURE 4
ENGINE AND DRIVE ASSEMBLY
1 64044-3 SCRW-SET3/8-16X5-16 2
2 64006-03 LCKWSHR-3/8 HEL 2
3 64006-03 WSHR, 3/8 HELICAL LCK 2
4 64123-50 BOLT-HEX 3/8-16X1 2
5 64123-15 BLT-CRG 1/4-20 X 3/4 2
6 548403 V-BELT 1
7 64123-75 BOLT-3/8-16X3 HEX 4
8 64164-25 KEY-1/4X7/8 #807 2
9 64163-82 WASHR,.39 1.25.19 FLAT 4
10 64268-01 NUT-FL NYLOCK 1/4-20 2
11 516892 PULLEY, REEL BELT 1
12 517101 PULLEY,3 IN. DIA BLK 1
13 517123 SHAFT 1
14 64164-13 KEY,.25 X2 SQ 1
15 838790 SPACER, ENG MNT PLTD 4
16 519809 PILLOW BLOCK 1
17 521856 BEARING,BALL 1
18 521857 COLLAR,BRG LOCKING 1
19 547755 COUPLING 1
(INCLUDES ITEMS 20 & 21)
20 64189-15 SCRW,.31-18 1.00 BS HS 2
21 64006-16 LWSHR,.31.09 HI-COLLAR 2
22 547759 BELT,DRIVE, SET OF 3 1
23 64163-31 WSHR 25/64X1X12 2
24 64044-18 SETSCREW, 5/16-18 X 5/16 2
25 64268-03 NUT-FL NYLOCK 3/8-16 4
26 4166458.7 PLTAE-ENGINE MOUNT 1
27 64018-2 BLT-CRG 1/4-20 X 3/4 2
28 4166459.7 GUIDE-BELT ADJ 1
