41
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
MATAWAY
FIGURE 7
REEL 1/32" BLADES-1/2" SPACING
1 305134 NUT,.88-14 YS HX JAM 1
2 516901 BLADE, 1/32" (0.8mm) 36
3 516903 SPACER, .500 (12.7mm) 36
4 521857 COLLAR,BRG LOCKING 2
5 544287 BLOCK AY,PILLOW 1
(INCLUDES ITEM 6)
6 548354 RING, INTERNAL RETAIN 1
7 545640 PILLOW BLOCK AY 1
(INCLUDES ITEM 8)
8 544292 BEARING 1
(INCLUDES ITEM 9)
9 521856 BEARING,BALL 1
10 820484 WASHER, FLAT 3
(USE ITEM 16 AS REQUIRED SO ITEM 1
DOES NOT CONTACT THE HEX SHAFT
WHEN TIGHTENED)
11* 544260A REEL 1
(INCLUDES ITEMS 1-16)
12 64164-19 KEY, WOODRUFF 1
13 522542 SHAFT 1
14 522543 PULLEY 1
15 522545 RING,RETAINING 1
NOTE:
THIS REEL ASSEMBLY IS BEST USED
FOR PULVERIZING CORES AFTER
AERATING.
BLADES ARE SPACED AT 1/2"
INTERVALS ON THE REEL.
DEPTH OF CUTTING SHOULD BE
LIMITED WHEN USING CLOSELY
SPACED BLADES.
* NOT ILLUSTRATED
