45
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
MATAWAY
FIGURE 9
REEL 1/16" BLADES-1" SPACING
1 305134 NUT,.88-14 YS HX JAM 1
2 516900 BLADE, 1/16" (1.5mm) 20
3 516905 SPACER, .900 (23mm) 20
4 521857 COLLAR,BRG LOCKING 2
5 544287 BLOCK AY,PILLOW 1
(INCLUDES ITEM 6)
6 548354 RING, INTERNAL RETAIN 1
7 545640 PILLOW BLOCK AY 1
(INCLUDES ITEM 8)
8 544292 BEARING ASSY 1
(INCLUDES ITEM 9)
9 521856 BEARING,BALL 1
10 820484 WASHER, FLAT 3
(USE ITEM 16 AS REQUIRED SO ITEM 1
DOES NOT CONTACT THE HEX SHAFT
WHEN TIGHTENED)
11* 544262A REEL 1
(INCLUDES ITEMS 1-10,12-16)
12 64164-19 KEY, WOODRUFF 1
13 522542 SHAFT 1
14 522543 PULLEY 1
15 522545 RING,RETAINING 1
NOTE:
THIS REEL ASSEMBLY IS BEST USED
FOR RENOVATING HEAVY GRASSES
AND BEFORE OVERSEEDING.
BLADES ARE SPACED AT 1" INTERVALS
ON THE REEL.
* NOT ILLUSTRATED
