MATAWAY
FIGURE 10
REEL 1/16" BLADES-1-1/2" SPACING
1 305134 NUT,.88-14 YS HX JAM 1
2 516900 BLADE, 1/16" (1.5mm) 14
3 516903 SPACER, .500 (12.7mm) 13
4 516905 SPACER, .900 (23mm) 13
5 521857 COLLAR,BRG LOCKING 2
6 544287 BLOCK AY,PILLOW 1
(INCLUDES ITEM 7)
7 548354 RING, INTERNAL RETAIN 1
8 545640 PILLOW BLOCK AY 1
(INCLUDES ITEM 9)
9 544292 BEARING ASSY 1
(INCLUDES ITEM 10)
10 521856 BEARING,BALL 1
11 820484 WASHER, FLAT 3
(USE ITEM 17 AS REQUIRED SO ITEM 1
DOES NOT CONTACT THE HEX SHAFT
WHEN TIGHTENED)
12* 544265A REEL 1
(INCLUDES ITEMS 1-11,13-17)
13 64164-19 KEY, WOODRUFF 1
14 522542 SHAFT 1
15 522543 PULLEY 1
16 522545 RING,RETAINING 1
NOTE:
THIS REEL ASSEMBLY IS BEST USED
FOR RENOVATING AND THINNING ALL
COARSE STEMMED GRASSES.
BLADES ARE SPACED AT 1" INTERVALS
ON THE REEL.
* NOT ILLUSTRATED
