49
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
MATAWAY
FIGURE 11
REEL FLAIL BLADES-1" SPACING
1 306956 COTTER PIN 6
2 516897 BLADE,FLAIL 36
3 517155 SHAFT 6
4 517162 SPACER, .328 (8mm) 24
5 517163 SPACER, .891 (23mm) 24
6 521857 COLLAR,BRG LOCKING 2
7 544287 BLOCK AY,PILLOW 1
(INCLUDES ITEM 8)
8 548354 RING, INTERNAL RETAIN 1
9 545640 PILLOW BLOCK AY 1
(INCLUDES ITEMS 10-12)
10 544292 BEARING ASST 1
(INCLUDES ITEMS 11)
11 545913.7 SHAFT AY 1
12 521857 COLLAR,BRG LOCKING 1
13* 544269A REEL 1
(INCLUDES ITEMS 1-12,14-17)
14 64164-19 KEY, WOODRUFF 1
15 522543 PULLEY 1
16 522545 RING,RETAINING 1
NOTE:
THIS REEL ASSEMBLY IS BEST USED
FOR THATCH CONTROL AND FOR
PULVERIZING CORES AFTER AERATING.
BLADES ARE SPACED AT 1" INTERVALS
ON THE REEL.
* NOT ILLUSTRATED
