ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
JR SOD CUTTER
FIGURE 1
DRIVE ASSEMBLY AND SIDE COVER
1 64163-55 WASHER .328X.75X14 GA 5
2 64006-03 LOCKWSHR-HELICAL 3/8 15
3 64001-13 NUT-HEX JAM 1/4-20 2
4 64123-67 BLT-HEX 3/8-16X2 1
5 64139-01 BLT-WLF 5/16-24X3/4 4
6 64123-50 BOLT-HEX 3/8-16X1 14
7 64123-68 BOLT-HEX 5/16-18X1 5
8 64123-269 BLT-HEX 1/4-20X1-1/8 1
9 64139-23 BLT-WLF 5/16-18 X 1-3/4 4
10 64139-10 BLT-WLF 5/16-18X1-1/4 1
11 64123-15 BOLT-3/8-16X3/4 HEX 1
12 64141-6 NUT, 5/16-18 4
13 4129801 BEARING-FLANGE 2
14 64163-67 WASHER-.516X1X12GA 2
15 85010N ZERK-GREASE 1
16 64176-11 PIN-COILED SPRING 3/16X1 2
17 517137 PULLEY,4" DIA "A" SIZE 1
18 64044-18 SCREW-SET 5/16-18 x 5/16 2
19 518535 SPRING 1
20 4175979 ASSY-GEARCASE 12" 1
4175980 ASSY-GEARCASE 18"
21 64141-2 NUT-WLF 1/4-20 2
22 524773.2 BRACE-GUARD 1
23 520785 SPRING 1
24 4164474 ROD-CONTROL 1
25 838496 WASHER,.25 1.00.125 FLAT 1
26 64163-29 WASHER-21/64 X 1 X 11GA 1
27 4164506.7 SPACER-CASTER ASM 1
28 521087 SHAFT 1
29 4164546.7 GUIDE-BELT, JR 1
30 4163592 DECAL,WARNING HANDS 1
31 64163-55 WASHER .328X.75X14 GA 5
32 64141-13 NUT-WLF 1/2-13 2
33 520773.7 BRACKET 1
34 4163910.7 BRACKET, BELT GUARD,TOP 1
35 524473.2 PLATE,ENGINE MOUNT 1
36 64139-02 BLT-WLF 1/4-20X1/2 2
37 4163353 S-GUARD ASSY 1
38 4175997 S-WLDMT, REAR WHL SPRT 1
(ITEMS 13 & 15 INCLUDED)
39 4164477.7 WLDMT-CLEVIS 1
40 831888 SWIVEL 1
41 831889 WASHER,SWIVEL 1
42 831890 SCRW,SWIVEL THROTTLE 1
(ITEMS 40-42 USED ON HONDA ENGINES ONLY)
43 545380.2 GUIDE AY, BELT 1
44 64123-87 BOLT-HEX 3/8-16X1-3/4 2
45 4164580.7 BRKT-BELT GUARD,BTTM 1
46 4175972.7 GUARD AY, FRONT 1
47 4133034 LABEL-JR SOD CUTTER 1
48 524573 BAND, BRAKE 1
49 64025-14 NUT-HEX #10-32 1
50 4164571.7 WLDMT-IDLER ARM 1
51 4163976 LABEL-RYAN 1
52 64168-2 HAIRPIN 2
53 819337 BUSHING 1
54 524610.7 BRACKET,BELT GUIDE 1
55 524574 NUT, BRAKE BAND 1
56 64044-22 SCREW-SET #10-32X1 1
(ITEMS 55, 56, 49 & 48 ARE AVAILABLE
IN BRAKE BAND KIT 540274)
57 64163-31 WSHR 25/64X1X12 6
58 64141-9 NUT-WLF 5/16-18 EL 1
59 64164-11 KEY-3/16X3/16X1-1/4 SQ END 1
60 524582 BELT,V A SECT. 66" LONG 1
USED ON HONDA MODELS
4178455 BELT- A X 67 1
USED ON B & S MODELS
61 64139-06 BLT-WLH 5/16-18X5/8 6
62 2702464 BUSHING,ISOLATION 1
63 548942 PULLEY, PLAIN IDLER 3.25" 1
64 800889 NUT,.31-18 SPD J W/NUT 2
65 64268-03 NUT-FL NYLON LOCK 3/8-16 3
66 4175971 LABEL-RYAN 1
67 340830 LABEL-CAUTION SPANISH 1
* NOT ILLUSTRATED
