31
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
JR SOD CUTTER
FIGURE 2
GEAR CASE
1 4175979 ASSY-GEARCASE 12" 1
4175980 ASSY-GEARCASE 18"
(INCLUDES ITEMS 1-74)
2 64123-67 BLT-HEX 3/8-16X2 1
3 64123-80 BLT-HEX 1/4-20X1-1/4 2
4 64006-02 LCKWSHER-HELICAL 5/16 12
5 64164-19 KEY WOODRUFF.19X.75 #9 3
6 64006-01 LOCKWASHER-1/4 HELICAL 4
7 64123-68 BOLT-HEX 5/16-18X1 12
8 515891 SHIM,.64 1.25.010 YS 4
9 4175981 HANDLE-SHIFTER,DRIVE 1
10 4175982 HANDLE-SHIFTER, CUT 1
11 515901.7 PULLEY 1
12 516145 GEAR 1
13 516150 GEAR 1
14 516156 SHAFT 1
15 516194 SPRING 2
16 516196 SPRING 2
17 520238 SHIM .005 (.13MM) A/R
18 520239 SHIM .010 (.25MM) A/R
19 520240 SHIM .020 (.51MM) A/R
20 520671.7 GEARCASE 1
21 521941 SPACER,1.00 1.12.66 1
22 548954 SEAL-OIL 1.38 SHAFT 2
23 64006-03 WSHR, 3/8 HELICAL LOCK 1
24 548931 PLUG,EXPANSION 1.75 YS 1
25 64164-28 KEY-#808 WOODRUFF 4
26 4139758 GEAR 1
27 516162 SPROCKET, CLUTCH 1
28 516172 CLUTCH 1
29 516173 SHAFT 1
30 544215 CAGE ASSY,BEARING 1
(INCLUDES ITEMS 31, 32)
31 548131 BRG,BALL 1.00 2.00.50 "DA" 1
32 548326 RING,INT RET 2.21OD.06 1
33 548327 RING-LOCK 1
34 544217.7 SHIFTER AY 1
35 545050 CAGE AY,BEARING 1
(INCLUDES ITEM 36)
36 814474 CUP,TPRD RLR BRG 1
37 516160 SPROCKET 1
38 521253 SHAFT-ECCENTRIC 1
39 548336 LOCK RING (KC) 1
40 814473 CONE,TPRD RLR BRG 1.00 2
41 545710 SHAFT AY 1
42 546033.7 DIPSTICK AY 1
43 546037.7 COVER AY, GEAR CASE 1
44 519404 GEAR,DRIVE 1
(INCLUDES ITEMS 45-47)
45 548775 PLUG.25-18NPTF HS 1
46 516222 HUB 1
47 548329 RING,EXT LOCK 1.61ID.06T 1
48 546937 CHAIN, #50 DOUBLE 1
49 547427 SPROCKET & SHAFT AY 1
50 548080 BRG.NDL.75 1.00.75 4
51 548096 BRG,BALL.59 1.38.43 "SS" 1
52 548272 SEAL,OIL 1.00 SHAFT 2
53 548321 RING,EXT RET.56ID.037 1
54 548323 RING, INTRNL RETAINING 2
55 548324 RING,EXT RET.691ID 2
56 548477 WASHER 4
57 548478 WSHR,.641 1.188.04 YS FLT 5
58 548482 PLUG,EXPANSION 1.25 YS 4
59 548597 LOCKNUT, UNI-TORQUE 2
60 548726 SCRW,.25-20.75 YS RS 4
61 4139759 SPACER-GEAR 1
62 307665 NUT .75-16 YS HX JAM 2
63 309799 LWSHR .75 ZS SHKPRF 2
64 520722 SPACER 2
65 520723 SHAFT 2
66 545626 SPROCKET AY 1
67 547398 CHAIN AY #50 RLR 1
68 547408.7 WHEEL AY 12IN 2
(USED ON 544951H & 544953C ONLY)
547424.7 WHEEL AY 18IN
(USED ON 544952H & 544954C ONLY)
69 64164-10 KEY 1/4X1-1/4 SQ 2
70 548952 RING INTERNAL RETAINING 2
71 548953 BRG-BALL 1.38 2.83.67 2
72 4117675 LINK-#50 CONNECTOR A/R
73 548480 LINK-HALF A/R
