Ryobi 4060310 - Tools Needed; Installing the Miter Slot Table; Assembly

4
TOOLS NEEDED
Fig. 3
INSTALLING THE MITER SLOT TABLE
See Figure 3.
■ Turn the ON/OFF switch to the OFF position.
■ Unplug the saw from the switched on-board outlet.
■ Disconnect the saw from the power supply.
■ Remove the sliding miter table and accessory table
from the saw.
■ Place the miter slot table onto the saw as shown in
Figure 3.
WARNING:
The table saw should never be connected to a power
supply while you are assembling parts. Disconnect-
ing the table saw will prevent accidental starting that
could cause serious personal injury.
ASSEMBLY
7/16 in. NUT DRIVER
Fig. 2
3/16 in. HEX KEY
1/4-20 x 1 in.
HEX CAP SCREW
WASHER
1/4-20 NUT
SHIMS
MITER
SLOT TABLE
