Model 454
Ref.
No.
Part No. Part Description
1. 747-1152 Shift Rod
2. 649-0041 Upper Handle Ass’y
3. 649-0034 Lower Handle Ass’y
4. 710-3005 Hex Screw 3/8-16 x 1.25
5. 710-3056 Hex Screw 5/16-18 x 3.25
6. 711-0415 Clevis Pin 3/8-1.62
7. 712-0379 Flange Lock Nut 3/8-24
8. 712-0429 Hex Lock Nut 5/16-18
9. 714-0147 Cotter Pin
10. 720-0313 Grip
11. 720-0210A T-Knob
12. 720-0278A Foam Grip
14. 726-0317 Cable Tie
15. 735-0246 End Plug
16. 736-0117 Flat Washer 3/8 ID x.620 OD
17. 736-0242 Bell Washer.340 ID x.872 OD
18. 738-0958 Shoulder Spacer
19. 784-0190 Handle Adjustment Crank
20. 784-0191 Hex Nut Retainer Bracket
21. 786-0120 Depth Stake
22. 747-1219 Clutch Bail
23. 786-0181 Shift Rod Lever
24. 686-0044A End Cover Ass’y
25. 710-0176 Hex Cap Screw 5/16-18 x 2.75
26. 710-3008 Hex Cap Screw 5/16-18 x.750
27. 710-3097 Carriage Bolt 3/8-16 x 1.0
28. 712-0421 Wing Nut
29. 736-0169 Lock Washer 3/8
30. 712-3004A Flange Nut 5/16-18
31. 726-0106 Cap Nut
32. 738-0849 Hex Screw 5/16-18 x.75”
33. 747-0432 Rod
34. 750-0885A Spacer.322 x.625 x 2.0
35. 786-0090 Side Shield
36. 786-0113 Rear Tine Shield
37. 786-0176 RH Handle Mounting Bracket
38. 786-0177 LH Handle Mounting Bracket
39. 786-0178 Tine Shield
40. 786-0179 Tine Shield Bracket
41. 786-0180 Front Tine Shield Scraper Bracket
42. 686-0109 Shift Crank Ass’y
44. 710-1017 Screw 1/4-14 x.625
46. 715-0120 Spiral Pin 3/16 x 1.0
49. 784-0208C Shift Cover
50. 784-0160 Tine Adapter Ass’y
51. 712-3054 Hex Nut 3/8-24
53. 742-0305 13” Articulating Tine
54. 738-0689 Shoulder Bolt
55. 736-0208 Flat Washer.51” ID x 1.50” OD
56. 736-0253 Bell Washer.515” ID x 1.14” OD
57. 738-0688 Shoulder Bolt
58. 784-0205 Tine Ass’y Complete
59. 714-0149B Internal Cotter Pin
60. 735-0127 Rubber Washer
61. 714-0104 Cotter Pin
62. 710-3022 Hex Screw 3/8-16 x 2.75”
63. 736-0204 Flat Washer
64. 712-0431 Flange Nut.344 ID x.62 OD
65. 736-0169 Lock Washer
66. 712-0798 Hex Nut 3/8-16
67. 710-0946 Truss Screw 1/4-20 x.65
68. 712-0324 Hex Lock Nut 1/4-20
69. 726-0273 Battery Hose Clamp 5/16
70. 736-3090 Flat Washer.260 ID x.720 OD
Ref.
No.
Part No. Part Description
