19
Model 454
Ref.
No.
Part No. Part Description
1. 686-0111 Belt Cover Bracket Ass’y
2. 710-0237 Hex Bolt 5/16-24 x.62”
3. 710-0412 Hex Bolt 1/4-28 x.75”
4. 710-0502A Hex Washer Screw 3/8-16 x 1.25”
5. 710-0152 Hex Bolt 3/8-24 x 1.0
6. 710-0599 Hex Washer Screw
7. 710-0723 Hex Cap Screw 3/8-16 x 1.25
8. 712-0266 Lock Jam Nut 3/8-16
9. 712-0267 Hex Nut 5/16-18
10. 714-0104 Internal Cotter Pin
11. 736-0104 Lock Washer 5/16
12. 736-0119 Lock Washer 5/16”
13. 736-0176 Flat Washer.25 ID x.93 OD
14. 736-0271 Spring Washer.317 ID x.625 OD
15. 736-0329 Lock Washer 1/4” ID
16. 736-0452 Bell Washer.396 ID x 1.14 OD
17. 738-0876 Shoulder Nut 7/16-20
18. 746-1117 Clutch Cable
19. 747-1159 Idler Pulley Rod
20. 754-0434 V-Belt 4L x 58.16 Lg
21. 756-0405 Flat Idler w/Flange 3.75 OD
22. 756-0971 Engine Inner Pulley Half
23. 756-0972 Engine Outer Pulley Half
24. 756-1162 Input Pulley
25. 786-0064A Idler Pulley Bracket
26. 785-0186 Belt Keeper Bracket
27. 786-0187 Shift Cover Bracket
28. 786-0193 Idler Belt Keeper
29. 634-0238 Wheel Assembly RH 16 x 4 x 8
634-0239 Wheel Assembly LH 16 x 4 x 8
734-0808 Tire Only 16.2 x 4.6
30. 634-0108 Wheel Rim Assembly
31. 734-0255 Air Valve
32. 711-1017 Clevis Pin
33. 710-0805 Hex Bolt 5/16-18 x 1.50
34. 710-0382 Hex Bolt 1/2-13 x 5.0
35. 712-0206 Hex Nut 1/2-13
36. 731-1595 Counterweight
37. 736-0179 Flat Washer.50 ID x 1.25 OD
38. 736-0921 Lock Washer 1/2
39. 710-0653 Hex Screw 1/4-20 x.375
40. 710-1017 Screw 1/4-14 x.625
41. 712-0392 Lock Nut
42. 736-3020 Flat Washer.271 ID x.630 OD
43. 784-0158A Belt Cover
44. 736-0242 Bell Washer.340 ID x.872 OD
45. 712-3010 Hex Nut 5/16-18
Ref.
No.
Part No. Part Description
NOTE: For painted parts, please refer to the list of color codes below. Please add the applicable color code, wherever needed,
to the part number to order a replacement part. For instance, if a part numbered 700-xxxx is painted Oyster Gray, the part
number to order would be 700-xxxx-0662.
Black — 0691; Black, Powder — 0637; Blue, Midnight — 0667; Charcoal — 0483; Grey — 0648;
Grey, Oyster — 0662; Orange — 0606; Red — 0650; Red, MTD — 0638; Silver — 0629; Yellow — 0674.
