3
ADDITIONAL BATTERY SAFETY WARNINGS
WARNING
To reduce the risk of re, personal injury, and product
damage due to a short circuit, never immerse your
tool, battery pack or charger in uid or allow a uid to
ow inside them. Corrosive or conductive uids, such
as seawater, certain industrial chemicals, and bleach
or bleach-containing products, etc., can cause a short
circuit.
SPECIFICATIONS
4V lithium-ion screwdriver
Model CSD41
Motor 4 V DC
Switch Single Speed /
Reversible
No load speed (Drill mode): 180 r/min.(RPM)
Clutch
12 Positions
Torque 5 Nm max
Collet 6.35 mm
Weight (included battery) 0.47 kg
Maximum Drilling Capacity Dia. 5.0mm
Charger Rating
Input: 230/240V-AC 50Hz
Output: 4.5/4.7V-DC 160mA
Charge Time 10 -12 hours
Measured sound values determined according to EN 60745:
A-weighted Sound pressure level L
pA
= 62 dB(A)
Uncertainty K 3 dB
A-weighted Sound power level L
WA
= 73 dB(A)
Uncertainty K 3 dB
Wear ear protectors.
The vibration total values (triaxial vector sum)
determined according to EN 60745:
Screwdriving without impact a
h
= 0.6 m/s
2
Uncertainty K 1.5 m/s²
Drilling into metal a
h,D
= 0.8 m/s²
Uncertainty K 1.5 m/s²
RESIDUAL RISKS
Even when the product is used as prescribed, it is still
impossible to completely eliminate certain residual risk
factors. The following hazards may arise and the operator
should pay special attention to avoid the following:
Damage to hearing caused by noise
Wear suitable hearing protection and limit exposure.
Injury to the eyes
Wear protective eye shields or goggles when using the
product.
Injury caused by vibration
Limit exposure. Follow the instructions in Risk
Reduction.
Electric shock caused by contact with hidden wires
Hold the product only by insulated services.
Injury caused by dust
Dust created by operating the product can cause
respiratory injury. Wear appropriate dust control mask
with filters suitable for protecting against particles from
the material being worked on.
RISK REDUCTION
It has been reported that vibrations from hand-held tools
may contribute to a condition called Raynaud’s Syndrome
in certain individuals. Symptoms may include tingling,
numbness and blanching of the ngers, usually apparent
upon exposure to cold. Hereditary factors, exposure to
cold and dampness, diet, smoking and work practices
are all thought to contribute to the development of these
symptoms. There are measures that can be taken by the
operator to possibly reduce the effects of vibration:
Keep your body warm in cold weather. When operating
the unit wear gloves to keep the hands and wrists
warm. It is reported that cold weather is a major factor
contributing to Raynaud’s Syndrome.
After each period of operation, exercise to increase
blood circulation.
Take frequent work breaks. Limit the amount of
exposure per day.
If you experience any of the symptoms of this condition,
immediately discontinue use and see your doctor about
these symptoms.
WARNING
Injuries may be caused, or aggravated, by prolonged
use of a tool. When using any tool for prolonged
periods, ensure you take regular breaks.
OPERATION
WARNING
Do not allow familiarity with products to make you
careless. Remember that a careless fraction of a
second is sufcient to inict serious injury.
