WARNING
Always wear safety goggles or safety glasses with side
shields when operating products. Failure to do so could
result in objects being thrown into your eyes, resulting
in possible serious injury.
WARNING
Do not use any attachments or accessories not
recommended by the manufacturer of this product. The
use of attachments or accessories not recommended
can result in serious personal injury.
TO CHARGE
See gure 2.
When charging the screwdriver, a red charge light will
illuminate on the handle of the screwdriver. This red charge
light will go off when the screwdriver is fully charged.
Insert charger plug into input jack making sure it is
properly connected.
Charger can be used with normal household voltage of
240 V, 50Hz, AC only.
Connect charger to power supply.
After normal usage, a minimum of 10-12 hours
charging time is required to fully recharge the
screwdriver.
Do not place charger in an area of extreme heat or
cold. It will work best at normal room temperature.
Remove the product from the charger once it is fully
charged and ready for use.
WARNING
Battery products are always in operating condition.
Therefore, the switch should always be locked when
not in use or carrying at your side.
ADJUSTABLE TORQUE CLUTCH
This screwdriver is equipped with an adjustable torque
clutch for driving different types of screws into different
mate ri als. The proper setting depends on the type of
material and the size of screw you are using.
ADJUSTING TORQUE
See gure 3.
There are twelve torque indicator settings located on the
front of the screwdriver.
Rotate adjustment ring to desired setting, aligning num
ber on adjustment ring with arrow on housing.
1 - 2 For driving small screws
3 - 4 For driving screws into soft material
5 - 7 For driving screws into soft and hard
materials
8 - 9 For driving screws into hard wood
10 - 11 For driving large screws
For full power applications
DIRECTION OF ROTATION SELECTOR
(FORWARD/REVERSE/CENTER LOCK)
See gure 4.
The direction of bit rotation is reversible and is controlled
by a selector located above the switch trigger. With the
screwdriver held in normal operating position, the direction
of rotation selector should be positioned to the left of the
switch trigger for forward motion. The direction is reversed
when the selector is to the right of the switch trigger.
Setting the switch trigger in the OFF (center lock) position
helps reduce the possibility of accidental starting when not
in use.
To stop the screwdriver, release the switch trigger and
allow the collet to come to a complete stop.
INSERTING/REMOVING BIT
See gure 5.
Insert the bit into collet until it snaps in place. Remove
the bit by pulling it out of the collet.
SPINDLE LOCK
The screwdriver spindle is locked when the On/Off switch
is not pressed.
This enables screws to be screwed in, even when the
battery is empty.
GRIP ZONE
Soft grip reduces the danger of slipping and thereby
improves the grip on the tool and handing.
At the same time, The rubber coating acheives a
vibrationreducing effect.
LED WORKLIGHT
See gure 6.
The screwdriver has a built-in LED worklight. This feature
is convenient when working in close or tight areas where
additional light is needed. Whenever the switch trigger is
depressed, the LED worklight will illuminate.
NOTE: During normal operation, if the LED worklight will
not illuminate, charge the screwdriver.
MAINTENANCE
WARNING
When servicing, use only original RYOBI replacement
parts. Use of any other parts may create a hazard or
cause product damage.
