Dust Extraction (Fig. 10)
You can use the dust bag provided or with the aid of the
adaptor accessory, connect the tool to a vacuum system.
The plastic dust extraction assembly ts in the dust port (9)
on the joiner. You can then attach a vacuum hose or the
supplied dust bag, to the adaptor.
Please note, when the bag becomes full, the dust will back-
up into the adaptor and the dust port. To clean them, turn off
and unplug the tool and remove the packed dust.
Maintenance
Do not allow brake uid, gasoline, and other petroleum
base products come in contact with the plastic parts of the
joiner. They contain chemicals that can damage, weaken
or destroy the housing of the tool and thus compromising
the integrity of the double insulation.
Keep the machine's air vents unclogged and clean at all
times. Remove dust and dirt regularly from the machine.
Cleaning is best done with compressed air or a rag. Re-
lubricate all exposed moving parts at regular intervals.
Fig. 10
MAINTENANCE
