Ryobi LCDI1802 User Manual

6



See Figure 3.
When not in use, bits provided with the drill can be
placed in the storage areas located on the base of the
drill.

See Figure 3.
The magnetic tray conveniently stores screws or other
small parts.
    

See Figure 10.
An auxiliary handle is packed with the drill for ease of
operation and to help prevent loss of control. The handle can
be mounted on the opposite side for left or right hand use.

 Loosen the handle assembly by turning the handle
counterclockwise.
 Insert the auxiliary handle assembly in the desired
operating position.
 Securely tighten by turning the auxiliary handle
clockwise.
 Be sure the auxiliary handle is securely tightened
against the depth stop rod clamp. This secures the depth
stop rod at the desired depth of cut. It also secures the
auxiliary handle.
The depth stop rod helps control the depth of drilled
holes. For convenience and ease of starting threads, the
hex nut has been trapped inside the molded slot in the
auxiliary handle.

 Lock the trigger switch by placing the rotation selector
in the center position.
 Loosen the auxiliary handle assembly by turning the
knob counterclockwise.
 Adjust the depth stop rod so that the drill bit extends
beyond the end of the rod to the required drilling
depth.
 Tighten the auxiliary handle assembly by turning the
knob clockwise.
 When properly installed, the teeth on the depth
stop rod should be aligned with the teeth indicator on the
depth stop rod clamp.

See Figure 9.
 Lock the trigger switch by placing the rotation selector
in the center position.
 Open or close the chuck jaws to a point where the
opening is slightly larger than the bit size you intend
to use. Also, raise the front of the drill slightly to keep
the bit from falling out of the chuck jaws.
 Insert the drill bit.
 Tighten the chuck jaws on the drill bit.
:
Make sure to insert the drill bit straight into the
chuck jaws. Do not insert the drill bit into the
chuck jaws at an angle then tighten. This could
cause the drill bit to be thrown from the drill,
resulting in possible serious personal injury or
damage to the chuck.
 Rotate the chuck body in the direction of the
arrow marked  to tighten the chuck jaws. Do not
use a wrench to tighten or loosen the chuck jaws.

See Figure 9.
 Lock the trigger switch by placing the rotation selector
in the center position.
 Open the chuck jaws.
 Rotate the chuck body in the direction of the
arrow marked  to loosen the chuck jaws. Do
not use a wrench to tighten or loosen the chuck jaws.
 Remove the drill bit.

 Check the rotation selector for the correct setting
(forward or reverse).
 Secure the material to be drilled in a vise or with
clamps to keep it from turning as the drill bit rotates.
 Hold the drill firmly and place the bit at the point to be
drilled.
 Depress the trigger switch to start the drill.
 Move the drill bit into the workpiece, applying only
enough pressure to keep the bit cutting. Do not force
the drill or apply side pressure to elongate a hole. Let
the tool do the work.
