4
Place the battery pack on the tool.
Make sure the latches on each side of the battery
pack snap into place and the battery pack is secured
on the tool before beginning operation.
Always remove battery pack from your tool when
you are assembling parts, making adjustments,
cleaning, or when not in use. Removing battery
pack will prevent accidental starting that could
cause serious personal injury.
See Figure 3.
Lock the trigger switch by placing the rotation selector
in the center position.
Depress the latches on the side of battery pack.
Remove the battery pack from the tool.
Battery tools are always in operating condition.
Therefore, the switch should always be locked
when not in use or carrying at your side.
See Figure 4.
To turn the drill , depress the trigger switch.
To turn it , release the trigger switch.
The variable speed trigger switch delivers higher speed
and torque with increased trigger pressure and lower
speed with decreased trigger pressure.
You might hear a whistling or ringing noise from
the switch during use. Do not be concerned; this is a
normal part of the switch function.
See Figure 4.
The bit rotation is reversible and is controlled by a
selector located above the trigger switch. With the drill
held in normal operating position, the rotation selector
should be positioned to the left of the trigger switch for
forward drilling. The drilling direction is reversed when
the selector is to the right of the trigger switch.
Setting the trigger switch in the (center lock) position
helps reduce the possibility of accidental starting when
not in use.
To prevent gear damage, always allow the chuck
to come to a complete stop before changing the
direction of rotation.
To stop the drill, release the trigger switch and allow the
chuck to come to a complete stop.
The drill will not run unless the rotation selector is
pushed fully to the left or right.
Avoid running the drill at low speeds for extended periods
of time. Running at low speeds under constant usage
may cause the drill to become overheated. If this occurs,
cool the drill by running it without a load and at full speed.
The internal spindle lock allows the user single-handed
control of chuck adjustments and bit changes. Squeezing
the chuck body stops the chuck jaws from turning. For
bit changes and chuck adjustments, squeeze the chuck
body and turn.
See Figure 5.
The drill has a keyless chuck to tighten or release drill
bits in the chuck jaws. The arrows on the chuck indicate
which direction to rotate the chuck body in order to
(tighten) or (release) the drill bit.
Do not hold the chuck with one hand and use the
power of the drill to tighten the chuck jaws on the
drill bit. The chuck body could slip in your hand,
or your hand could slip and come in contact with
the rotating drill bit. This could cause an accident
resulting in serious personal injury.
