4
English
SPECIFICATIONS
Motor 18 Volt
Blade Diameter 150mm
Blade Arbor 10mm
Cutting Depth at 0º 45mm
Cutting Depth at 45º 32mm
No Load Speed 4,200 min
-
1
MODEL
BATTERY
PACK
(not included)
COMPATIBLE
CHARGER
(not included)
LCS-180
BPL-1820
BPL-1815
BCL-1800
BCS618
BCL1418
ABP1801
ABP-1815
BCL-1800
BCS618
BCL1418
ACR1800
260022029
ACC1800
ASSEMBLY
WARNING
If any parts are damaged or missing do not
operate this product until the parts are replaced.
Failure to heed this warning could result in
serious personal injury.
WARNING
Do not attempt to modify this product or create
accessories not recommended for use with this
product. Any such alteration or modification is
misuse and could result in a hazardous condition
leading to possible serious personal injury.
WARNING
To prevent accidental starting that could cause
serious personal injury, always remove the
battery pack from the product when assembling
parts.
ATTACHING THE BLADE
See Figure 2.
WARNING
A 150mm. blade is the maximum blade capacity
of the saw. Never use a blade that is too thick
to allow outer blade washer to engage with the
flats on the spindle. Larger blades will come in
contact with the blade guard, while thicker blades
will prevent blade screw from securing blade on
spindle. Either of these situations could result in
a serious accident.
Remove the battery pack from the saw.
Remove the blade wrench (5 mm hex key) from the
storage area.
Depress the spindle lock button and remove the
blade screw and outer blade washer.
NOTE: Turn the blade screw clockwise to remove.
CAUTION
To prevent damage to the spindle or spindle lock,
always allow motor to come to a complete stop
before engaging spindle lock.
NOTE: Do not run the circular saw with spindle lock
engaged.
Wipe a drop of oil onto the inner blade washer and
outer blade washer where they contact the blade.
WARNING
If inner blade washer has been removed, replace
it before placing blade on spindle. Failure to do
so could cause an accident since blade will not
tighten properly.
Fit the saw blade inside the lower blade guard and
onto the spindle.
NOTE: The saw teeth point upward at the front of the
saw.
Replace the outer blade washer.
Depress the spindle lock button, then replace the
blade screw. Tighten the blade screw securely by
turning it counterclockwise.
Return the blade wrench to the storage area.
NOTE: Never use a blade that is too thick to allow
the outer blade washer to engage with the flats on the
spindle.
REMOVING THE BLADE
See Figure 3.
Remove the battery pack from the saw.
Remove the blade wrench from the storage area.
Position the saw as shown, depress the spindle lock
button, and remove the blade screw by turning it
clockwise.
Remove the outer blade washer.
Remove the blade.
BATTERY PROTECTION FEATURES
Ryobi 18 V lithium-ion batteries are designed with
features that protect the lithium-ion cells and maximize
