8
A - Battery port (logement de pile, receptáculo para batería)
B - Key hole hanger (trou de serrure pour la suspension, colgador tipo bocallave)
C - Bluetooth button (bouton Bluetooth, botón de Bluetooth)
D - LCD Screen (écran ACL, pantalla LCD)
E - Power button (bouton d’alimentation, botón de encendido)
A - Bluetooth Indicator (indicateur Bluetooth, indicador de Bluetooth)
B - State of charging percent (pourcentage d’état de charge, estado del porcentaje de carga)
C - Temperature delay Indicators (indicateurs de délai de température, indicadores de retraso de temperatura)
D - Battery charging indicator (indicateur de chargement de la pile, indicador de carga de la batería)
A
D
C
OP4010
Fig. 1
B
A
B
C
D
E
