FEATURES
Fig. 1
KEYLESS
CHUCK
BIT
STORAGE
TORQUE
ADJUSTMENT
RING
SWITCH
TRIGGER
LEVELS
TWO-SPEED
GEAR TRAIN (HI-LO)
MAG TRAY™
(SCREW HOLDER)
TOP VIEW OF LEVEL FOR
HORIZONTAL DRILLING
END VIEW OF LEVEL FOR
VERTICAL DRILLING
DIRECTION OF
ROTATION SELECTOR
(FORWARD/REVERSE/CENTER LOCK)
PRODUCT SPECIFICATIONS
Chuck .......................................................... 1/2 in. Keyless
Motor..................................................................18 Volt DC
Switch..........................................................Variable Speed
No Load Speed ....................................0-350/0-1,300/min.
Clutch.................................................................24 position
Torque.................................................. Maximum 330 in.lb.
Charger Input ................................... 120 V, 60 Hz, AC only
Charge Rate .............................................................1 Hour
