RYOBI 18 VOLT JIG SAW – MODEL NUMBER P521
4
SWITCH
MOTOR
RED
LEAD
YELLOW
LEAD
BLUE LEAD
BLACK LEAD
WIRING DIAGRAM
BLACK LEAD
RED LEAD
BLACK
LEAD
BLACK LEAD
BLACK
LEAD
RED LEAD
RED
LEAD
LASER
CONTACT
PLATE HOLDER
RED LEAD
