Ryobi R18XPCS10 - Replacing the Bar and Saw Chain; Initial Bar and Chain Replacement Steps

13
Maintenance
REPLACING THE BAR AND SAW
CHAIN
1. Remove the battery pack.
2. Pull up the guide bar locking knob, then
turn it counterclockwise to unlock.
3. Turn the chain tension knob
counterclockwise.
4. Remove the guide bar locking knob,
chain tension knob, and sprocket cover.
5. Remove the bar and saw chain assembly.
1
2
1
1
2
2
3
4
5
