Ryobi RBC430SBS - Page 9

8
ENGLISH
FEATURES
RBC430SES RBC430SBS
Engine Displacement 30 cm³ 30 cm³
Cutting Path Diameter 18 in / 457 mm 18 in / 457 mm
Line Diameter 2.4 & 2.7 mm 2.4 & 2.7 mm
Blade Diameter 200 mm 200 mm
Mass (without fuel, cutting attachment
and guard)
5.60 kg 6.10 kg
Mass (without fuel with line trimmer head) 5.90 kg 6.40 kg
Mass(without fuel, with blade head) 5.85 kg 6.35 kg
Volume (fuel tank) 350 cm³ 350 cm³
Engine oil volume
(recommended measurement)
77 ml 77 ml
Maximum engine perform
(in accordance with ISO8893)
0.70 kW 0.70 kW
Maximum rotational frequency of the spindle 10000/min 10000/min
Engine speed (rotational frequency) at
recommended max. spindle rotational
frequency
12000/min 12000/min
Engine speed (rotational frequency)
at idling
3000-3600/min 3000-3600/min
Fuel consumption (in accordance with
ISO8893) at max. engine performance
0.48 kg/h 0.48 kg/h
Specific fuel consumption (in accordance
with ISO8893) at max. engine
640 g/kW
.
h 640 g/kW
.
h
Vibration levels for idling and racing (for
idling and with wide open throttle for grass
trimmers) when measured in accordance
with 4.2 Vibration level idling for Left handle
and Right handle
N/A 0.75 m/s² and 0.55 m/s²
When measured in accordance with 4.2
Vibration level idling for Front handle and
Rear handle
0.74 m/s² and 0.56 m/s²
N/A
Vibration level racing for Left handle and
Right handle
N/A 2.18 m/s² and 3.10 m/s²
Vibration level racing for Front handle and
Rear handle
1.24 m/s² and 1.72 m/s² N/A
Sound pressure level (in accordance
with ISO 22868)
92 dB (A) 92 dB (A)
Sound power level (in accordance
with ISO 22868)
107 dB (A) 106 dB (A)
