11
ENGLISH
Read the safety information for safe operation using the
Tri-Arc
®
blade, refer to the general and specific safety
rules in this manual.
Always hold brush cutter/line trimmer on your right side
with both hands when operating. Use a firm grip on both
handles.
Maintain your grip and balance on both feet.
Position your self so that you will not be drawn off balance
by the kick back reaction of the cutting blade.
See Figures 8 - 9.
■ Avoid hot surfaces by always keeping the tool away
from your body. (Correct operating position shown in
figures 8-9).
■ Keep the brush cutter/line trimmer tilted toward the
area being cut; this is the best cutting area.
■ The brush cutter/line trimmer cuts when passing the
unit from right to left. This will avoid throwing debris at
the operator. Avoid cutting in dangerous areas.
CUTTING TECHNIQUE - TRIMMER LINE
■ Avoid hot surfaces by always keeping the tool away
from your body. (Correct operating position shown in
figure 8).
■ Keep the brush cutter/line trimmer tilted toward the
area being cut; this is the best cutting area.
■ The brush cutter/line trimmer cuts when passing the
unit from right to left. This will avoid throwing debris at
the operator. Avoid cutting in dangerous areas.
■ Use the tip of the line to do the cutting; do not force
string head into uncut grass.
■ Wire and picket fences cause extra line wear, even
breakage. Stone and brick walls, curbs, and wood
may wear line rapidly.
■ Avoid trees and shrubs. Tree bark, wood mouldings,
siding, and fence posts can easily be damaged by the
line.
GRASS DEFLECTOR LINE TRIMMING CUT-OFF
BLADE
See Figure 10.
The trimmer is equipped with a line trimming cut-off blade
on the grass deflector. For best cutting, advance line until
it is trimmed to length by the cut-off blade. Advance the
line whenever you hear the engine running faster than
normal, or when trimming efficiency diminishes. This
will maintain best performance and keep the line long
enough to advance correctly.
STARTING AND STOPPING
See Figure 11 - 13.
To start a cold engine:
DO NOT squeeze the throttle trigger until the engine
starts and runs.
■ Lay the brush cutter on a level surface.
■ Place the engine switch to the on “I” position.
■ PRIME - press the primer bulb 10 times slowly.
■ SET the choke lever to the “START” position.
■ PULL the starter rope with a quick firm and consistent
upward motion until the engine starts.
Note: If difficulties with starting are experienced
(this may occur in colder conditions) refer to
troubleshooting section in this manual.
■ Allow engine to warm up for 5-20 seconds, then
squeeze the throttle trigger to run.
Note: Squeezing the throttle trigger releases the
start lever to the RUN position.
To start a warm engine:
DO NOT squeeze the throttle trigger until the engine
starts and runs.
With the engine switch on “I” position; PULL the starter
rope with a quick firm and consistent upward motion until
the engine starts.
To stop the unit:
Place the engine switch to the stop “O” position.
MAINTENANCE
WARNING:
When servicing, use only identical replacement
parts. Use of any other parts may create a
hazard or cause product damage.
WARNING:
Always wear safety goggles or safety glasses
with side shields during tool operation. If
operation is dusty, also wear a dust mask.
WARNING:
Before inspecting, cleaning, or servicing the
machine, shut off engine, wait for all moving
parts to stop, and ensure the cut off switch
remains in the off position. Failure to follow these
instructions can result in serious personal injury
or property damage.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use.
Use clean cloths to remove dirt, dust, lubricant, grease.
WARNING:
Do not at any time let brake fluids, petrol,
petroleum-based products, penetrating
lubricants, etc., come in contact with plastic
parts. Chemicals can damage, weaken or
destroy plastic which may result in serious
personal injury.
RBC430SES/SBS manual(TTIA).indd Sec2:11RBC430SES/SBS manual(TTIA).indd Sec2:11 09-9-23 5:2509-9-23 5:25
