Ryobi RBV26B - KNOW YOUR PRODUCT; Product Component Identification; ASSEMBLY; Unpacking and Inspection

18
English (Original instructions)
Allow the engine to run for 10 seconds
before using the product.
To start a cold engine
To start a warm engine
Blower mode
If the quick change lever is pointing on
this symbol, the product operates in blow
mode.
Vacuum mode
If the quick change lever is pointing on
this symbol, the product operates in
vacuum mode
Conforms to all regulatory standards in
the country in the EU where the product
is purchased.
EurAsian conformity mark
Ukrainian mark of conformity
Guaranteed sound power level is 107 dB.
KNOW YOUR PRODUCT
See Fig 1a and 1b.
1. Lower vacuum tube
2. Vacuum bag
3. Adaptor
4. Cruise control
5. Throttle trigger
6. Upper vacuum tube
7. Fuel cap
8. Starter grip
9. Choke lever
10. Upper handle
11. On/Off switch
12. Positive switch at blowing side
13. Primer bulb
14. Vacuum handle
15. Upper blower tube
16. Door tab
17. Inlet cover
18. Lower blower tube
19. Positive switch at vacuuming side
20. Raised slot
21. Adaptor installed in vacuum bag
22. Raised locking tab with switch insert metal plate
23. Vacuum bag assembly
24. Vacuum Inlet cover tab
25. Vacuum opening
26. Locking tab
27. Vacuum tube assembly
28. Screw for holding vacuum tube assembly
29. Quick start label
30. High velocity nozzle
31. Air  lter cover
32. Air  lter dial - turn to open or close air  lter
33. Air  lter
34. Wrench
ASSEMBLY
UNPACKING
This product requires assembly.
Carefully remove the product and any accessories
from the box. Make sure that all items listed in the
packing list are included.
WARNING
Do not use the product if any parts on the packing list
are already assembled when you  rst open the box.
The parts on the packing list are not assembled by the
manufacturer and require customer installation. Use of
a product that may have been improperly assembled
could result in serious personal injury.
Carefully inspect the product to make sure no
breakage or damage occurred during shipping.
Do not discard the packing material until you have
carefully inspected and satisfactorily operated the
product.
If any parts are damaged or missing, please call your
Ryobi service centre for assistance.
PACKING LIST
Blower/vacuum
Blower tube
Nozzle
Upper blower tube
Lower blower tube
Adaptor installed in vacuum bag
Upper vacuum tube
Lower vacuum tube
Bottle of 2-stroke lubricant
Operators manual
