Ryobi RCS2340B User Manual

21
OPERATION
Bucking a log
1/3
2/3
2/3
1/3
WARNING: Kickback may occur when
the nose or tip of the guide bar touches
an object, or when the wood closes in and
pinches the saw chain in the cut.
WARNING: The reaction force is always
opposite to the direction the chain is moving.
Thus, the operator must be ready to control
the tendency for the product to pull away
(forward motion) when cutting on the bottom
bumper spike to avoid such movement. The
product can be pushed backwards (towards
the operator) when cutting along the top
edge. To avoid this make sure the chain
is not jammed when cutting along the top
edge.
NOTE: When the log is supported on both
ends, cut 1/3 the diameter from the top
cut.
NOTE: When the log is supported on one
end, cut 1/3 the diameter from the underside

Ryobi RCS2340B Specifications

General

Power source	AC
Idle speed	- RPM
Chain speed	16 m/s
Blade length	400 mm
Product color	Black, Green
Ergonomic handle	Yes
Oil tank capacity	0.15 L

Weight and Dimensions

Weight	4800 g
