Know your product
KNOW YOUR PRODUCT
NOTE: When Chain brake is activated,
the unit will not operate.
12 3
15 14
56
910
111213
16 1817
47
8
2019
1. Front hand guard/Chain brake
2. Front handle
3. Rear handle
4. Fuel mix cap
5. Chain lubricant cap
6. Silencer
7. Spiked bumper
8. Air filter
9. Switch
10. Starter grip
11. Chain catcher
12. Combination wrench
13. Choke lever
14. 3ULPHUEXOE
15. Throttle trigger
16. Trigger release
17. Locking tab
18. Air filter cover
19. Chain
20. Guide bar
