Ryobi RCS5050 - Cleaning the Air Filter

32
MAINTENANCE
2
3
2
1
2
4
1
ADDING OIL TO THE AIR FILTER
1. Stop the engine. Engage the chain
brake.
2. 3XOOWKHORFNLQJWDEXSZDUGV
3. 3XOOWKHDLUILOWHUFRYHUEDFNZDUGVDQGOLIW
it straight up to remove; set aside.
NOTE: Blow or brush as much loose dirt
and sawdust from around the carburettor
and chamber as possible.
Ensure the choke lever is in the full-
choke position to keep the carburettor
from being contaminated.
4. Lubricate the air filter with several drops
of chain and bar oil.
NOTE: $GGLQJ RLO WR WKH DLU ¿OWHU
HQKDQFHV¿OWUDWLRQ
