REPLACING THE BLADE
1. Disconnect the plug from the power
outlet.
WARNING: Replace the blade when
the blade wears down to the indication
line.
2. Insert the locking pin into the inner
ange washer. Using the combination
wrench, remove the blade nut, outer
ange washer and blade.
3. Install the new blade on the inner ange
washer and then reinstall the outer
ange washer, and blade nut. Secure
using the combination wrench. Make
approximately 3.5 turns after nger
tight to tighten the blade screw. The
recommended torque for the blade is
≥
25 Nm.
Remove the locking pin.
WARNING: Make sure the blade
is correctly installed and securely
fastened before each use.
