DESCRIPTION
1. Rear handle
2. Cable strain relief arm
3. Safety button
4. Trigger switch
5. Auxiliary handle
6. Auxiliary handle locking knob
7. Edging coupler
8. Knob for height adjustment
9. Telescopic tube
10. Motor housing
11. Edge guide
12. Foot pedal for head angle adjustment
13. Safety guard
14. Cutting head
15. Manual line feed button
STANDARD ACCESSORIES
Safety guard, Screw(4pcs)
