Ryobi RLT36BS - Page 16

14
OPERATION
33 cm
28 cm
28 cm
33 cm
2
1
1
2
x2
3
1
2
x2
33 cm
28 cm
1
2
3
ADJUSTING THE CUTTING WIDTH
1. Remove the battery pack.
2. Loosen the screws on the line cut-off blade.
Detach the line cut-off blade. Rotate the line
cut-off blade 180º.
NOTE: Runtime is decreased on 11 cm setting.
3. Install the line cut-off blade into the new
position. Tighten the screws to secure the
line cut-off blade to the guard.
