6
Servicing requires extreme care and knowledge and
should be performed only by a qualied service technician.
For service we suggest you return the product to your
nearest for repair.
When servicing, use only identical replacement parts.
To avoid serious personal injury, do not attempt
to use this product until you read thoroughly and
understand completely the operator’s manual. If you
do not understand the warnings and instructions in the
operator’s manual, do not use this product. Call Ryobi
customer service for assistance.
The operation of any power tool can result in foreign
objects being thrown into your eyes, which can result
in severe eye damage. Before beginning power tool
operation, always wear safety goggles or safety glasses
with side shields and, when needed, a full face shield.
We recommend Wide Vision Safety Mask for use
over eyeglasses or standard safety glasses with side
shields. Always use eye protection which is marked to
comply with ANSI Z87.1.
1. Bar
2. Chain
3. Pruner attachment
4. Chain oiler tank cap
5. Coupler
6. Extension shaft
7. “J” handle
8. Engine switch
9. Starter grip
10. Primer bulb
11. Throttle trigger
12. Shoulder strap
13. Knob
14. Scabbard
15. Combination wrench
7. “J” handle
16. Clamp
17. Long bolt
18. Flat washer
19. Lock nut
20. Latch
21. Bolt
22. Strap hanger
18. Flat washer
19. Lock nut
21. Bolt
5. Coupler
6. Extension shaft
13. Knob
23. Button
24. Guide recess
25. Positioning hole
26. Pruner attachment
27. Load
28. First cut ¼ in. diameter
29. Second cut
30. Final cut
31. Cutting guide
8. Engine switch
11. Throttle trigger
32. Trigger lock
33. Start position
34. Run position
35. Choke lever
8. Engine switch
9. Starter grip
10. Primer bulb
11. Throttle trigger
36. Starting instruction label
37. Flats
38. Approx 1.3 mm (0.050 in)
RPPGM_SAA_MAN_ENG_20110215_D8.indd 6 15/02/2011 11:38 AM
