7
1. Bar
2. Chain
39. Bar nut
40. Drivecase cover
39. Bar nut
40. Drivecase cover
41. Bar stud
42. Sprocket
43. Bar stud slot
44. Chain tensioning pin hole
2. Chain
39. Bar nut
42. Sprocket
44. Chain tensioning pin hole
45. Chain rotation
46. Chain tensioning screw
39. Bar nut
47. Idle speed screw
48. Bar lube reservoir
49. Remove cap
50. Replace cap
51. Top plate
52. Rivet hole
53. Heel
54. Gullet
55. Toe
52. Rivet hole
56. Depth gauge
57. Side plate
58. Cutting corner
59. Left hand cutters
60. Right hand cutters
61. Foam air lter
62. Air lter cover
63. Cover securing knob
64. Spark plug boot
65. Spark plug
Engine displacement 25.4 cc
Weight 7.1 kg
Pruner reach without extension 1850 mm (73 in)
Pruner reach with extension 2745 mm (108 in)
Fuel tank volume 620cm
3
Maximum engine performance (in
accordance with ISO 8893)
0.9kW
Engine speed (rotational
frequency) at recommended max.
spindle rotational frequency
12000 min
-1
Engine speed (rotational
frequency) at idle
2600-3200 min
-1
Fuel consumption (in accordance
with ISO 8893) at max. engine
performance
0.54 kg/h
Specific fuel consumption (in
accordance with ISO 8893) at max.
engine performance
0.50 kg/h
Vibration level idling
Front handle 3.8 m/s
2
Rear handle 3.8 m/s
2
Vibration level racing
Front handle 2.4 m/s
2
Rear handle 7.9 m/s
2
Sound pressure level (in accordance with Annex B of
EN ISO 11680-1 )
Idle 73.7 dB(A)
Racing 100.3 dB(A)
