Ryobi RTR400 - Page 2

1. On / Off switch
2. Base
3. External brush cap
4. Motor housing
5. Collet
6. Collet nut
7. Depth of cut scale
8. Wing bolt
9. Cutter
10. Wrench on collet nut
11. Wrench on spindle fl ats
12. Locking screw
13. Fence
14. Wing nut
15. Washer
16. Center hole
17. connector
18. Bolt
19. Nail (not included)
20. Bolt A (Locking screw)
21. Bolt C
22. Bolt B
23. Bit
24. Workpiece
25. Guide
26. Depth of cut
27. Width of cut
28. 1st pass
29. 2nd pass
30. Trimmer feed direction
31. Trim end grains fi rst
32. Brush assembly
33. Bit/cutter guard
34. Height adjust knob
35. Adjusting guide
DESCRIPTION
Fig. 1
Fig. 2
Fig. 3
9
10
11
1
1N.
1
/
2
1
2
3
4
7
34
8
5
6
1
1N.
1
/
2
34
8
7
