11
RYOBI 10 in. TABLE SAW – MODEL NUMBER RTS10
The model number will be found on a label attached to the cabinet. Always mention the model number in all correspondence regarding your 10 in.
TABLE SAW or when ordering parts.
PARTS LIST FOR SECTION "A"
1 0101010807 Screw w/Washer (M5 x 30 mm) ...................... 1
2 0121010242 Wire Clamp ..................................................... 1
3 410272004 Screw (M5 x 75 mm) ....................................... 2
4 089037007047 Motor Cord ..................................................... 1
5 089037007048 Wire Connector ............................................... 1
6 451010003 Strain Relief ..................................................... 1
7 0301025006 Carbon Brush .................................................. 2
8 089037007050 Brush Holder ................................................... 2
9 410252001 Screw w/Washer (M4 x 12 mm) ...................... 3
10 089037007049 Motor End Cap ............................................... 1
11 0101010209 Pad .................................................................. 2
12 411012001 Hex Nut (M5) ................................................... 4
13 089037007051 Motor Housing ................................................ 1
14 412061001 Wavy Washer (M6 x 16 mm) ........................... 1
15 089037007703 Field Assembly ................................................ 1
16 089037007052 Screw w/Washer (M5 x 70 mm, Hex Hd.) ....... 2
17 089037007053 Ball Bearing (6001ZZ C3) ................................ 1
18 089037007704 Armature Assembly
(Inc. Key Nos. 17 and 19) ................................ 1
19 089037007054 Ball Bearing (6201 ZZ C3) ............................... 1
20 410174721 Screw (8-32 x 3/8 in, Truss Hd.) ..................... 1
21 412042002 Lock Washer (D4) ............................................ 2
22 089037007055 Bearing Housing ............................................. 1
23 420110004 Needle Bearing ............................................... 1
24 089037007705 Arbor Assembly .............................................. 1
25 089037007060 Lower Blade Guard ......................................... 1
26 412042001 Lock Washer (D5) ............................................ 2
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
NOTE: The assembly shown represents an important part of the double insulated system. To avoid the possibility of alteration or damage to the system,
service should be performed by your nearest Ryobi Authorized Service Center. Contact your nearest Ryobi Authorized Service Center for service.
