RYOBI 10 in. TABLE SAW – MODEL NUMBER RTS10
The model number will be found on a label attached to the cabinet. Always mention the model number in all correspondence regarding your 10 in.
TABLE SAW or when ordering parts.
PARTS LIST FOR FIGURE A
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
57 089037007700 Blade Guard Assembly
(Inc. Key Nos. 51-56) .......................................1
58 080015001437 Screw (1/4-20 x 3-1/4 in, Hex Hd.) ..................2
59 410162003 Screw (M6 x 18 mm, Cheese Hd.) ...................3
60 0101010905 Spacer (D9.5 x 68 mm) ....................................2
61 414011002 Pin (D8 x 90 mm) .............................................1
62 089037007029 C-Ring ..............................................................1
63 411071001 Washer (D1/4 x D16 x 2t) .................................6
64 089037007033 Block ...............................................................1
65 089037007034 Hex Nut (3/8-16) ..............................................2
66 089037007031 Screw (M8 x 9.5 mm, Hex Hd.) ........................1
67 089037007030 Indicator Bracket .............................................1
68 089037007032 Indicator ...........................................................1
69 089110101066 Screw w/Washer (M4 x 12 mm, Pan Hd.) .......1
70 089037007102 Washer (D6.5 x D20 x 1.6t) ..............................3
71 080015001455 Hex Nut (1/4-20) ..............................................1
72 089037007036 Work Plate ........................................................1
73 089037007035 Bolt (1/4-20 x 40 mm) ......................................1
74 089037007701 Anti-Kickback Pawl Assembly .........................1
75 089037007706 Rip Fence Assembly ........................................1
76 089037007707 Miter Gauge Assembly ....................................1
77 0101010312 Wrench (Closed End) .......................................1
78 0101010313 Wrench (Open End) ..........................................1
79 0101140903 Hex Key (M5 x 75 mm) ....................................1
Not Shown:
987000864 Operator’s Manual (089037008193) ................1
5-13-10
(Rev:03)
