RYOBI 10 in. TABLE SAW – MODEL NUMBER RTS21
The model number will be found on a label attached to the cabinet. Always mention the model number in all correspondence regarding your
10 in. PORTABLE TABLE SAW or when ordering parts.
PARTS LIST FOR SECTION “A”
1 089037007047 Motor Cord ...................................................... 1
2 089037007048 Terminal ............................................................ 1
3 410252001 Screw w/Washer (M4 x 12 mm, Pan Hd.) ........ 3
4 089037007049 Motor Rear Cap ............................................... 1
5 0101010209 Brush Holder Clamp ........................................ 2
6 080015001427 Hex Nut (M5) .................................................... 2
7 089037011050 Screw w/Washer (M5 x 35 mm, Pan Hd.) ........ 3
8 089037007051 Motor Housing ................................................. 1
9 089037011028 Field Assembly ................................................. 1
10 089037007052 Screw w/Washer (M5 x 70 mm, Hex Hd.) ........ 2
 11 089037007053 BallBearing(6001ZZ)龍 ...................................... 1
12 089037011708 Armature Assembly
(Inc. Key Nos 11 and 13) ................................. 1
13 089037007054 Ball Bearing (6201ZLU C3) .............................. 1
14 089037007055 Gear Box .......................................................... 1
15 420110004 Needle Bearing (HK0910) ................................ 1
16 089037011029 Arbor Assembly ............................................... 1
17 451010003 Strain Relief ...................................................... 1
18 089037007050 Brush Holder .................................................... 2
19 0301025006 Brush ............................................................... 2
20 0121010242 Wire Clamp ...................................................... 1
21 412061001 Wave Washer ................................................... 1
22 410174721 Screw (8#-32 x 3/8 in., Pan Hd.) ...................... 1
23 412042002 External Tooth Lock Washer (D4) ..................... 2
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
