RYOBI 10 in. TABLE SAW – MODEL NUMBER RTS21
The model number will be found on a label attached to the cabinet. Always mention the model number in all correspondence regarding your
10 in. PORTABLE TABLE SAW or when ordering parts.
PARTS LIST FOR FIGURE A
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
56 089037007032 Indicator ........................................................... 1
57 089037011013 Indicator Bracket ............................................. 1
58 411061001 Toothed Hex Nut (M6) ...................................... 4
59 410192001 Screw (M4 x 10 mm, Pan Hd.) ......................... 3
60 089037007031 Screw (M4 x 10 mm, Hex Hd.) ......................... 1
61 0101010920 Arbor Nut ......................................................... 1
62 0101010302 Outer Blade Washer ......................................... 1
63 422010025 Saw Blade ........................................................ 1
64 089037007017 Screw (M4 x 0.7 mm) ....................................... 3
65 411071001 Lock Nut (M6) .................................................. 3
66 089037007018 Screw (M6 x 15 mm) ........................................ 1
67 089037007019 Lever ................................................................ 1
68 089037011027 Screw (M5 x 25 mm) ........................................ 4
69 089037007020 Clamp Lock ...................................................... 1
70 089037007021 Clamp .............................................................. 1
71 089037007097 Plate ................................................................. 1
72 089037007098 Bracket ............................................................ 1
73 412011007 Washer (D5 x D12 x 1.5t) ................................. 2
74 412021005 Lock Washer (M5) ............................................ 2
75 089037007101 Screw (M5 x 10 mm, Button Soc. Hd.) ............ 2
76 089037011709 Motor Assembly ............................................... 1
77 412011701 Washer (D1/4 in. x D16 x 1t) ............................ 2
78 410551701 Screw w/Washer (1/4-20 x 1/2 in., Pan Hd.) .... 2
79 089037011053 Extension Rod (Front) ...................................... 1
80 089037011054 Extension Rod (Rear) ....................................... 1
81 089037007022 Screw (M6 x 20 mm, Hex Hd.) ......................... 2
82 089037007023 Mounting Bracket ............................................ 1
83 089037007702 Riving Knife ...................................................... 1
84 089037011030 Clamping Bracket ............................................ 1
85 089037011031 Spring .............................................................. 1
86 089037007709 Lever Assembly ............................................... 1
87 089037007700 Blade Guard Assembly
(Inc. Key Nos. 95-100) ..................................... 1
88 089037007701 Anti-Kickback Pawls Assembly ....................... 1
89 089037011018 Rear Support ................................................... 1
90 089037011019 Rear Rod .......................................................... 2
91 089037011014 Extension Table ................................................ 1
92 089037011005 Saw Table ........................................................ 1
93 089037011020 Outfeed Support Bracket ................................. 2
94 089037011704 Rip Fence Assembly (See Figure C) ................ 1
95 089037007910 Front Blade Guard Warning Label (Left) .......... 1
96 089037007909 Front Blade Guard Warning Label (Right) ........ 1
97 089110113913 No Hands Warning Label ................................. 2
98 089037007912 Guard Warning Label (Left) .............................. 1
99 089037007911 Guard Warning Label (Right) ............................ 1
100 089037007908 Warning Label (Upper Barrier) ......................... 1
Not Shown:
089037011021 Dado Throat Plate (Optional) ........................... 1
988000930 Operator’s Manual (089037011908)
3-15-13
(Rev:03)
