The following items are included with your table saw:
A. Front Stand Leg (“A”) .........................................................1
B. Rear Stand Leg (“B”) ..........................................................1
C. Front Stand Leg (“C”) .........................................................1
D. Rear Stand Leg (“D”) ..........................................................1
E. Blade Guard with Anti-Kickback Pawls .............................1
F. Push Stick ..........................................................................1
G. Miter Gauge (In Storage Area) ...........................................1
H. Rip Fence ...........................................................................1
I. Open End Blade Wrench (In Storage Area) ........................1
J. Closed End Blade Wrench (In Storage Area) .....................1
K. Hex Key (5 mm) ..................................................................1
L. Sliding Table Assembly ......................................................1
M. Stop Screw ........................................................................1
N. Rip Indicator End Cap ........................................................1
O. Indicator .............................................................................1
P. Screw (M4 x 25 mm, Truss Hd.) .........................................1
Q. Bolt (M5 x 35 mm) ..............................................................4
R. Lock Nut (M5).....................................................................4
S. Crosspiece .........................................................................1
T. Wheel .................................................................................2
U. Washer (OD16 x ID8 x 2t) ...................................................4
V. Lock Nut (M8).....................................................................4
W. Self-tapping Screw ............................................................4
G
H
U
T
V
O
E
N
L
Q
M
K
F
S
C
D
B
A
W
P
R
J
I
LOOSE PARTS
