25 - English
ASSEMBLY
TO MOVE THE SAW
See Figure 24.
Close the leg stand as described earlier in the To open/
close (set-up/tear down) the leg stand section.
Holding the leg stand firmly, pull the leg stand toward you
until the leg stand and saw are balanced on the wheels
like a handtruck.
Push the saw to the desired location then either open the
leg stand for immediate saw operation or store the saw
in a dry environment.
STORING TABLE SAW ACCESSORIES
See Figure 25 - 28.
When not in use the rip fence, riving knife, wrenches, blade
guard, miter gauge, and push stick may be stored beneath
the saw table.
Fig. 28
RIVING
KNIFE STORAGE
PUSH STICK
KNOB
BLADE WRENCH STORAGE
Fig. 24
Fig. 26
Fig. 27
BLADE
GUARD
STORAGE
BLADE
GUARD
RIP
FENCE
RIP FENCE
STORAGE
BLADE
WRENCHES
Fig. 25
RIP FENCE
STORAGE
MITER GAUGE
STORAGE
KNOB
MITER
GAUGE
