9 — English
MAINTENANCE
Fig. 9
ATTACHING THE STORAGE HANGER
See Figure 10.
There are two ways to hang the attachment for storage.
To use the hanger cap, push in the button and place the
hanger cap over the end of the attachment shaft. Slightly
rotate the cap from side to side until the button locks into
place.
The secondary hole in the attachment shaft can be used
for hanging purposes as well.
STORING THE ATTACHMENT
Store the attachment in a dry, well-ventilated place that
is inaccessible to children.
Keep away from corrosive agents such as garden chemi-
cals and de-icing salts.
Fig. 10
BUTTON
HOLE
HANGER
CAP
SECONDARY
HOLE
HOLDING PIN
INSERTED INTO
ALIGNED SLOTS
BLADE NUT
Fig. 8
1/2 in.
SOCKET WRENCH
BLADE
LOWER FLANGE
WASHER
FLANGE
