Ryobi RY34421 - Parts List (Figure A)

3
RYOBI 30cc STRING TRIMMERS
MODEL NUMBERS – RY34420, RY34440
19 518949001 Wing Nut (1/4-20) .................................................. 1
20 518142002 Top Cover ..............................................................1
21 518696002 Throttle Trigger ......................................................1
22 690694002 Throttle Trigger Spring ...........................................1
23 518366001 Hanger Cap ........................................................... 1
24 308439014 Throttle Cable and Lead Assembly
(Incl. Key No. 5) .....................................................1
25 940680023 Hot Surface Label ..................................................1
26 940734040 Starting Label ........................................................ 1
27 120950028 Upper Boom Assembly (Incl. Key No. 28) .............1
28 940230132 Warning Label ........................................................ 1
29 940705020 Logo Label .............................................................1
30 940991026 C430 Label (RY34420) ........................................... 1
940991027 S430 Label (RY34440) ...........................................1
31 570400001 O-Ring ................................................................... 1
987000405 Operator’s Manual (960646002) ............................ 1
9-17-08
(REV:00)
1 660563002 Screw (M4 x 20 mm) ..............................................4
2 120950026 Control Handle Assembly ...................................... 1
3 518695002 Trigger Lock ........................................................... 1
4 638431001 Strap Hanger ......................................................... 1
5 760700002 Switch (Momentary Contact) .................................1
6 570234002 Rear Handle ........................................................... 1
7 678029002 Hex Nut (M6.3 x 1) .................................................1
8 310586001 Fuel Cap Assembly ................................................1
9 120950027 Air Box Cover (Incl. Key No. 26) ............................1
10 310302001 Oil Cap/Dipstick (Incl. Key No. 31) ........................1
11 870217001 Spark Plug (Champion RZ7C) ............................... 1
12 660634001 Screw (#8-16 x 5/16 in.).........................................1
13 T660697001 Bolt (M6 x 1 x 30 mm) ...........................................1
14 660510004 Screw (M5 x .8 in.) ................................................. 1
15 308991001 Front Handle Assembly
(Incl. Key No. 16-19) .............................................. 1
16 518738001 Front Handle ..........................................................1
17 660643008 Bolt (1/4-20 x 40 mm) ............................................ 1
18 678008001 Washer (1/4 in.) ...................................................... 1
PARTS LIST (FIGURE A)
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
